Place of Origin:
Made in China
Brand Name:
TL
Certification:
MSDS, UN38.3, IEC62133
Model Number:
TL-EB-H36C
|
Nominal Voltage
|
36V
|
|
|
Nominal Capacity
|
18.2ah 20.8ah, 23.2ah
|
|
|
Continuous discharge current
|
35A(max)
|
|
|
Burst Discharge Current
|
54A(adjustable)
|
|
|
Power
|
500-1500W
|
|
|
Over-charged Protection Voltage
|
4.25±0.025V/Cell(adjustable)
|
|
|
Over -discharged Protection Voltage
|
2.50±0.10V/Cell(adjustable)
|
|
|
Charge mode
|
CCCV
|
|
|
Max charge Voltage
|
56V
|
|
|
Charging Current
|
2.0-4.0A
|
|
|
Charging Temperature
|
0~45ºC,45~85%RH
|
|
|
Discharging Temperature
|
-20~55ºC,45~85%RH
|
|
|
Circle life
|
>500 times
|
|
|
Storage Environment
|
One Month
|
-20~+55ºC,45~85%RH
|
|
Three Month
|
-20~+45ºC,45~85%RH
|
|
|
One Year
|
-5~+20ºC,45~85%RH
|
|
|
Dimension
|
high
|
reference sample
|
|
length
|
reference sample
|
|
|
thickness
|
reference sample
|
|
|
Weight
|
<5.0 KG
|
|
